System Requirements
7 Stone Control Center Software
For all Windows versions, it is recommended that the latest Microsoft service pack is deployed. NVR recording throughput and retention times can vary according to the number of cameras, camera resolution, estimated percent of motion, continuous recording settings and predefined retention period.
FOR FULL SERVER PERFORMANCE, SEE THE 7 STONE CERTIFIED SOLUTION.
Client Software
- Preloaded with 7 Stone Control Center (ACC) Client software
- Supports high resolution monitors
- Includes the adapters and accessories for quick deployment
- 7 Stone warranty and support included
| SYSTEM REQUIREMENTS | MINIMUM | RECOMMENDED |
|---|---|---|
| Operating System | Windows 8.1 / 10 (64-bit) with Microsoft .NET 4.6.2 | Windows 10 (64-bit) with Microsoft .NET 4.6.2 |
| Processor | Intel® dual-core CPU (2.0 GHz) | 8th Generation Intel Celeron® CPU or higher |
| Memory | 4 GB DDR3 | 8 GB DDR4 |
| Video | PCI Express, DirectX 10.0 compliant with 256 MB RAM | NVIDIA® Quadro P620 |
| Storage | 500 MB free disk space | 500 MB free disk space |
Server Software
- Optimized for video surveillance applications in a 24/7/365 environment
- 7 Stone Control Center (ACC) software is preinstalled, configured and enhanced for optimal system compatibility
- Certified for the 7 Stone surveillance environment: ACC software, LPR, Mobile Gateway, Analytics, HDSM and 1–30 MP cameras
- High throughputs of up to 1800 Mbps
- Documented network architecture for a wide-variety of applications
- 7 Stone enhanced warranty and premium support included
- Access to 7 Stone System Design Tool (SDT) to calculate storage requirements
| SYSTEM REQUIREMENTS | MINIMUM | RECOMMENDED |
|---|---|---|
| Operating System | Windows Server 2012 R2 / 2016 / 2019, Windows 8.1 / 10 (64- bit) | Windows Server 2016 |
| Processor | x86 64-bit (dual-core, 1.9 GHz) | Intel® Xeon® E5 v3 (6 cores, 1.9GHz) |
| Memory | 4 GB DDR3 | 16 GB DDR4 |
| Storage | SATA-II 7200 RPM Enterprise Class | SATA-III 7200 RPM Enterprise Class |
